Sand Mill

Name: Sand Mill
Brand: CHEM-MACO

Get a Price/Quote

MOQ : 100 Pieces

Sand Mill Specification

Voltage
220V/380V

Production Capacity
50-250 Liters/hour

Noise Level
Low

Model No
SMHK/HSM Series

Frame Type
Heavy-duty, welded frame

Motor Power
3 HP, 5 HP, 7.5 HP, 10 HP, 15 HP

Frequency
50 Hz

Drive
Direct/ Belt Drive

Accuracy
High precision grinding and dispersing

Lubricating System
Grease Lubrication

Power Rating
3 HP 15 HP

Features
Easy operation, robust construction, high efficiency, low maintenance

Operating Temperature
Ambient to 60C

Machine Type
Horizontal Sand Mill

Control System
Manual/electrical panel

Cooling System
Water Jacketed

Product Type
Industrial Sand Mill

Technology
Wet Grinding, Dispersing

Power Source
Electric

Operating Type
Automatic / Semi-automatic

Power
Standard (Exact wattage not specified)

Pressure
Atmospheric to moderate (Exact value not specified)

Surface Treatment
Powder Coated

Dimension (L*W*H)
As per model (customizable)

Weight (kg)
Approximately 180 kg (varies by model)

Color
Blue & Silver

Usage & Applications
Paints, Inks, Pigments, Dye, Pharmaceuticals, Coatings

Feeding Type
Continuous

Safety Features
Overload protection, safety interlocks

Mixer Type
Agitator

Chamber Material
Stainless Steel / Mild Steel

Rotor/Stator Type
Pin/Disc

WorkingSpeed
1440 RPM

Seal Type
Mechanical Seal

Cleaning Method
CIP (Clean In Place)/ Manual

End-use Industries
Paint, Coating, Ink, Chemical Processing, Pharmaceutical

Minimum Batch Size
1 Liter

Discharge Type
Bottom / Side

Bead Size Suitable
0.8 2.5 mm

Main Shaft Material
SS 316 / Hardened Alloy Steel

Maximum Viscosity Processed
up to 10,000 cP

Number of Blades/Discs
Variable (depending on chamber size)

Sand Mill Trade Information

Minimum Order Quantity
100 Pieces

Supply Ability
1 Piece Per Week

Delivery Time
7 Days

About Sand Mill

SPECIFICATION

Power	5HP to 25HP
Capacity	5 Liters to 30 Liters
Material	Stainless Steel
Flame Proof Version	Available
Mill Chamber Volume	5 Liters to 30 Liters
Milling Media Type	Zirconium Grinding Beads or Glass Beads
Country of Origin	Made in India

Versatile Chamber and Shaft Materials

Select between stainless steel or mild steel chambers and main shafts crafted from SS 316 or hardened alloy steel, ensuring durability and compatibility with diverse production requirements. These material choices accommodate a wide range of chemicals and process conditions, providing optimal product longevity and corrosion resistance.

Advanced Grinding and Dispersing Technology

The sand mill employs a combination of pin or disc-type rotors and stators for efficient wet grinding, dispersing pigments, dyes, and chemicals with high precision. It handles batch sizes as small as one liter, offers customizable blade/disc configurations, and ensures low noise operation for user comfort.

Efficient Operation and User Safety

Benefit from features such as mechanical sealing, overload protection, and integrated safety interlocks. The water jacketed cooling system maintains stable operating temperatures, while the direct or belt drive system delivers reliable, quiet power for continuous operation.

Flexible Cleaning and Maintenance

Maintain hygiene with easy-to-clean design options: choose CIP (Clean In Place) for automated cleaning or manual cleaning as needed. Powder-coated surfaces and heavy-duty welded frames contribute to low maintenance and prolong machine life, making it an ideal choice for demanding industrial environments.

FAQ's of Sand Mill:

Q: How does the sand mill ensure efficient and precise grinding?

A: The sand mill utilizes a combination of pin/disc-type rotors and stators, along with optimized chamber and bead configurations, to achieve high-precision wet grinding and uniform dispersion. Its agitator mixer ensures consistent product quality throughout the process.

Q: What industries and applications is this sand mill suitable for?

A: Designed for versatility, this sand mill is ideal for paint, coating, ink, pigment, dye, chemical processing, and pharmaceutical industries. It efficiently processes a variety of slurry viscosities, making it suitable for both laboratory and large-scale production.

Q: When should I use CIP (Clean In Place) versus manual cleaning methods?

A: CIP is recommended for frequent cleaning cycles, particularly in industries where hygiene is critical, such as pharmaceuticals or food-grade chemical processing. Manual cleaning is suitable for less frequent cleaning needs or smaller batch production.

Q: Where is the sand mill manufactured and can it be exported?

A: The sand mill is manufactured in India, where it is supported by established exporter, manufacturer, and supplier networks. It is available for domestic use and global export, with customizable features to meet local requirements.

Q: What is the recommended process flow for operating the sand mill?

A: Feed the material continuously into the chamber with the appropriate bead size loaded. The agitator disperses and grinds the slurry while maintaining desired viscosity and temperature. After processing, product is discharged from the bottom or side outlet, depending on your setup.

Q: How does the machine's cooling and safety system enhance operation?

A: A water-jacketed chamber keeps processing temperatures stable, preventing product degradation and equipment overheating. Safety is ensured through mechanical seals, overload protection, and electrical safety interlocks, reducing downtime and operator risks.

Q: What are the key benefits of using this sand mill in industrial settings?

A: Key advantages include high efficiency, low maintenance, reliable safety features, precise grinding, low noise level, and ease of operation. Its customizable, heavy-duty construction supports demanding continuous or semi-automatic workflows, contributing to increased productivity and product quality.
